The same precision, held to your industry's standard.

Medical instrumentation metal fabrication demands precision, traceability, and single-source accountability. At Evans Tool & Die, we manufacture metal components for diagnostic equipment, laboratory systems, and healthcare devices. Through high-precision stamping for diagnostic equipment combined with in-house tooling and secondary operations, our Conyers, GA facility eliminates hand-offs between tool shops and production floors.

The Advantage of In-House Tool and Die for Complex Geometries

With over 200 years of combined experience, the master tool makers at Evans tackle complex medical equipment housing design without external shop dependencies. Integrating these steps directly into the workflow cuts weeks from development timelines.

In-house tool and die for medical components means absolute control over clearances, punch wear monitoring, and die maintenance schedules. When diagnostic instruments require brackets with ±.0005 in. positioning accuracy, tool makers build those exact specifications into the progressive dies.

During forming operations, DFM for medical equipment housings addresses crucial material flow dynamics. Tool designers proactively account for springback, grain direction, and surface finish requirements specific to medical applications.

Quality Assurance: ISO 9001:2015 and Material Traceability

To ensure consistent process stability, inspectors execute first-article verification, 30-minute in-process checks, and complete final part evaluations before packaging. Statistical process control continuously tracks critical dimensions.

Maintaining strict compliance for medical OEMs requires rigorous, documented systems:

• Material traceability in medical manufacturing. Tracking starts with certified mill test reports. Lot numbers link finished components back to the original coil for device master files and regulatory submissions.
• ISO 9001:2015 certified medical stamping. Documented procedures establish baseline process controls and fuel continuous improvement. Incoming material inspection consistently verifies chemical composition and mechanical properties before production begins.

Scaling Production From 30 to 1,000 Tons

Scaling from 30 to 1,000 tons, the press floor accommodates everything from small internal brackets to large medical frame assemblies requiring 800-ton forming forces. Progressive die stamping for medical assemblies achieves speeds up to 1,200 strokes per minute when part geometry allows automated feeding.

High-tonnage equipment also brings economic benefits to multi-part medical kits, allowing several components to nest together in a single progressive die. This approach maintains consistent dimensional relationships between mating features. For example, 1,000-ton presses provide high-precision stamping for diagnostic equipment enclosures while keeping springback to an absolute minimum.

Beyond Stamping: Laser Cutting and Robotic Welding

Providing full-service fabrication extends beyond the press floor. Evans offers specialized secondary operations tailored to complex medical manufacturing:

• Custom laser cutting for medical instruments. This process handles low-volume prototype runs and geometrically complex parts. A 6kW fiber laser cuts stainless steel with accuracy, holding ±.0005" to ensure precise edge profiles.
• Robotic welding for medical device fabrication. Automated systems deliver consistent penetration and minimal distortion. Programmed weld paths for MIG and TIG processes produce assemblies with highly repeatable bead profiles.
• Material selection guidance. Choosing between types of stainless steel for medical devices presents a key design trade-off. Some types offer excellent formability for deep-drawn components, whereas others provide superior corrosion resistance in surgical environments exposed to chloride-containing fluids.

Medical Instrumentation Fabrication

Partnering with a single-source manufacturer reduces lead times and eliminates coordination risk. By combining in-house tool and die for medical components, high-precision stamping for diagnostic equipment, and secondary operations under one roof, Evans protects your supply chain. Material traceability in medical manufacturing and ISO 9001:2015 certified medical stamping confidently support your device development from prototype through full production.

Metal stamping for the automotive industry is a critical process that transforms flat metal sheets into precise, complex vehicle components for structural, functional, and aesthetic purposes. At Evans Tool & Die, we specialize in producing custom, high-volume solutions for our automotive customers. We use advanced technologies such as deep drawing, progressive die stamping, and transfer stamping to meet tight tolerances. Our fabrication solutions address the growing demand for lightweight, durable, and seamlessly integrated automotive components.

Benefits of Custom Automotive Metal Stamping

Custom automotive metal stamping from Evans Tool & Die offers manufacturers full control of the design process, which leads to improvements in the following areas of production:

• Precision and accuracy. Our custom designs meet strict tolerances and specifications to make sure all components perform as intended.
• Cost-effectiveness. The scalable process of custom metal stamping can reduce material waste, optimize resources, and lower production costs.
• Durability. Our parts are engineered for reliable, long-lasting performance under extreme conditions.
• Design flexibility. Custom metal stamping lets us create intricate shapes and complex geometries to meet any design need while adhering to industry standards. The customization process produces innovative part designs that reduce vehicle weight, improve fuel efficiency, and enhance safety standards.
• Material versatility. We offer many material options, including lightweight aluminum, stainless steel, and high-strength steel.

The Automotive Stamping Process

At Evans Tool & Die, our automotive stamping process ensures precision, quality, and efficiency through the following steps:

• Tooling design. Each project begins with custom die and tool engineering tailored to your exact specifications.
• Material selection. We'll choose the best metals for the project based on strength, weight, and corrosion resistance needs.
• Stamping. We use advanced techniques like progressive and transfer stamping to deliver high-quality, consistent parts at scale.
• Secondary processes. Our team offers additional services to complete components, including welding, surface treatments, and assembly.
• Quality assurance. We conduct rigorous inspections at every stage to ensure all parts meet industry and client-specific standards.

By integrating cutting-edge technology with skilled craftsmanship, our stamping process helps manufacturers meet production timelines without compromising quality or performance.

Types of Automotive Stampings We Make

Evans Tool & Die produces a diverse range of components for automotive applications, optimized for safety, cost-effectiveness, and performance:

• Structural components: body panels, chassis supports, structural reinforcements
• Functional parts: suspension systems, heat shields, exhaust components
• Hardware: brackets, fasteners, clips
• Interior systems: parts for dashboards, seats, and doors
• Drivetrain components: transmission and suspension parts

Applications of Automotive Metal Stamping

Automotive metal stamping produces critical parts for all types of vehicles, including:

• All-terrain vehicles (ATVs). Durable and lightweight components such as skid plates and brackets enhance performance in rugged environments. We typically fabricate these components from high-strength aluminum.
• Commercial vehicles. We produce heavy-duty chassis supports and load-bearing brackets from high-strength steel to withstand extended operational lifespans.
• Passenger vehicles. We design precision-stamped parts, including exhaust shields, body panels, and dashboard reinforcements, to improve fuel efficiency and meet strict safety standards.

Learn More About Quality Automotive Stamping Parts by Evans Tool & Die

At Evans Tool & Die, we combine decades of experience with a relentless focus on innovation, ensuring our solutions stay ahead of industry trends. Our precision-crafted parts are designed to integrate seamlessly into modern automotive systems while meeting the highest standards of durability and efficiency. We use cutting-edge technologies and a customer-first approach to deliver low- to high-volume solutions that drive safety and performance.

In the construction industry, builders, structural engineers, and structural framers choose materials that are strong and durable for supporting loads in buildings and structures. Cost-effectiveness and ease of installation are also important for using resources efficiently and meeting project timelines.

At Evans Tool & Die we provide metal stamping and laser cutting services for many construction applications from building materials to equipment parts and beyond. Learn more about our capabilities and services for the construction industry as well as some common applications of our work.

Precision Metal Stamping and Laser Cutting for Construction Components

Many types of metal structural elements, fastening and support components, and parts used in power tools are fabricated with metal stamping and laser cutting processes. Both of these high-precision operations are quick, repeatable, and known for efficient use of materials.

In construction applications, it's important for materials to be uniform and manufactured to meet OEM and customer requirements so that structural pieces fit correctly in framing assemblies, brackets hold pieces in place without torquing, and tool parts stand up to heavy use and jobsite wear and tear. Therefore, the ability to stamp and cut components to specified dimensions with necessary part features is critical.

The Benefits of Metal Stamping and Laser Cutting for Construction Applications

Both metal stamping and laser cutting offer numerous advantages in the construction industry.

Metal Stamping

Metal stamping uses cutting tools and dies mounted into a high-tonnage stamping press. As the upper tooling moves downward onto a sheet or strip of metal, specific shapes and features are formed. Material is held in close alignment throughout the process, which results in high accuracy and repeatability cycle after cycle. Evans manufactures all tooling and dies in-house. Some of the benefits of stamping components include:

• Strength and durability. Metal stamping is compatible with many types and thicknesses of material including alloys, steel, and aluminum. As a result, it's possible to fabricate a range of part types from very small delicate and intricate brackets to heavier yet simple shapes.
• Accuracy and precision. Metal stamping tooling and guiding elements are designed and manufactured to make the specified part features within very tight tolerances, so there is little variation between parts. This means assemblies fit together better, features like notches and holes are aligned correctly, and components are highly uniform.
• Cost-effectiveness. Metal stamping is cost-effective thanks to its very low error rate, which results in less scrap and wasted material. Stamping is suitable for both low- and high-volume production, and it requires less energy and labor than machining and alternative processes.
• Versatility. There are many different stamping operations, from shearing and blanking to piercing, bending, notching, and others. This means it can be used to form a wide range of parts efficiently and reliably. Stamping is also suitable for highly customized parts and components.

Laser Cutting

Laser cutting uses a computer to guide a powerful laser along a predetermined cutting path. It makes precise, clean cuts that need little to no additional finishing. It offers these advantages:

• Accuracy and precision. Laser cutting offers a combination of precision and accuracy with every cut, which is necessary in construction for developing parts with tight tolerances and complex designs. Laser cutting is also highly repeatable because all of the laser's movements are controlled by computerized work instructions.
• Efficiency and speed. The laser's power and the speed of the arm holding it can be adjusted to best suit the type and thickness of the material being cut. This means laser cutting is very fast, but it can also be slowed down when necessary to maintain clean cut edges and tolerances, depending on the material and component in question.
• Material versatility. Lasers can be used to cut many different materials including steel, stainless steel, aluminum, and wood.
• Minimal material waste. In laser cutting, the layout of how pieces are cut out of a sheet of metal is designed to generate minimal waste. The goal is to get as much from each sheet of material as possible.

Construction Industry Applications

Metal stamping and laser cutting are useful processes for many applications in or related to the construction industry.

Steel Pallets

The interlocking pieces of a steel pallet can be laser cut for clean cut edges and precise dimensions that assemble easily.

I-Beams

Also called H-beams with an H-shaped cross section, I-beams consist of a vertical "web" and "I"-shaped flanges. Lasers can be used to cut holes and other features into them for use with fasteners in structural assemblies.

Brackets and Connectors

Truss plates, joist hangers, gang nail plates, and other types of brackets and connectors can be stamped from steel or other metals.

Equipment Parts

Many of the parts used in construction equipment are stamped or laser cut, including components in frames, fuel tanks, heat shields, enclosures, tank straps, and toggle switch guards.

Power Tools

Some of the parts in saws, grinders, and drills are manufactured by stamping or laser cutting. Jigs and other devices used with them may contain stamped parts also.

Your Trusted Fabricator for Construction Applications

Evans Tool & Die is a trusted supplier of custom metal stampings and laser cutting services for customers in the construction industry. We also provide welding, machining, sheet metal fabrication, finishing, and engineering support for a complete solution for your custom manufacturing projects.

The appliance and lighting industries rely on high-performance parts that are both long-lasting and exceptionally reliable. From electrical housings and mounting brackets to decorative lighting assemblies, stamped metal components play a critical role in appliance and lighting manufacturing. Evans Tool & Die manufactures precision metal stampings and fabricated components designed to meet both functional performance requirements and cosmetic finish standards.

Advanced Fabrication Capabilities for the Appliance Sector

To meet the rigorous demands of commercial and residential appliance manufacturing, your supply chain requires a partner with diverse, scalable capabilities. We leverage advanced technology to produce components with exact tolerances and superior durability. Our core metal stamping and fabrication capabilities include:

• Heavy Weld Fabrication: Used for structural frames and heavy-gauge assemblies in commercial appliance and industrial equipment applications.
• Large Deep Draw Stamping: Supports the production of seamless appliance housings, drums, and lighting reflectors while maintaining material strength.
• Laser Cutting Preparation: Supports tight tolerances and clean edge quality for complex appliance and lighting components prior to forming or assembly.
• Progressive Stamping: Highly efficient, cost-effective, and high-volume production designed for smaller, repetitive parts like electrical contacts, mounting clips, and brackets.
• Robotic Welding: Provides consistent, repeatable weld quality for high-volume appliance and lighting assemblies.

High-Strength Materials for Lighting and Appliances

Selecting the optimal material is critical for managing thermal conductivity, ensuring electrical safety, and achieving cosmetic perfection. Evans Tool & Die works with a broad spectrum of high-strength materials tailored to the specific functional and aesthetic requirements of the appliance sector.

• Aluminum: Lightweight, highly reflective for custom lighting fixtures, and naturally corrosion-resistant.
• Brass & Copper: Industry-standard metals provide excellent electrical conductivity for sockets and internal wiring assemblies.
• Stainless Steel: Durable and corrosion-resistant with a clean finish suitable for exposed appliance surfaces.
• Cold-Rolled & Draw Quality Steel: Delivers a superior strength-to-weight ratio; perfect for heavy structural chassis and deep-drawn housings.
• Sheet Metal: Formable and cost-effective for brackets, heat shields, panels, and other fabricated components.

Quality Components for Everyday Appliances

OEM appliance and lighting manufacturers require components that maintain dimensional accuracy, support reliable assembly, and meet cosmetic finish expectations. Whether you are producing commercial-grade kitchen equipment or modern smart home devices, the integrity of the internal and external components dictates the quality of the final product.

Evans Tool & Die supports the production of custom lighting components, appliance housings, brackets, and precision-stamped electrical parts for both commercial and residential applications. Through controlled manufacturing processes and tight tolerance capabilities, Evans Tool & Die produces components designed for consistent fit, repeatable assembly, and long production runs.
